Thin Glass Slides & Cover Glasses

UQG Thin glass slides and cover glasses are produced from drawn and floated glasses. The quality of the glass surface produces high transmission and excellent smooth surface finishes to very precise thickness. Our stock range is made from chemically resistant Borosilicate glass D263M of the first hydrolytic class for thickness to 0.20m thick. Above 0.20mm thick we use Schott D263® T eco glass. Widely used in the science and medical industries for use in laboratories in universities, analytical research, biomedical and R&D research. Suitable for fluorescence microscopy, optical and display applications used in counting chambers, haemacytometers and glass covers for micro plates. Custom sizes are made in all thicknesses with options of pre-cleaned and interleaved or supplied cut and packed.

Please contact our sales team.

BOROSILICATE SCHOTT D 263 ®T eco Thin Glass
Dimensions: Diameters 5mm to 150mm
Squares/Rectangles 1mm x 1mm to 440mm x 360mm
Thickness Range: 0.30mm to 0.70mm
Edge Finish: As cut or ground
Surface Quality: Diffused
Material Options: Schott D263 ® T eco Thin Glass
Coating Options: AR coatings
BOROSILICATE SCHOTT D 263 ®M Cover Glass
Dimensions: Diameters 5mm to 150mm
Squares/Rectangles 1mm x 1mm to 410mm x 435mm
Thickness Range: 0.05mm to 0.20mm
Edge Finish: As cut or ground
Surface Quality: Diffused
Material Options: Schott D 263 ®M Cover Glass
Coating Options: AR coatings

Purchase or OEM production quantities?
Ask UQG for a quote we are a major single source supply chain global supplier.

Material:
Schott D 263 ®T Eco Thin Glass
Dimension Tolerance:
± 0.20mm
Thickness Range:
No3 (0.28mm to 0.32mm) 0.30mm
No4 (0.38mm to 0.42mm) 0.40mm
No5 (0.55mm ±0.05mm) 0.55mm
No7 (0.70mm ±0.05mm) 0.70mm
Edge Finish:
As cut
Surface Quality:
60/40 Scratch/Dig
Surface Roughness:
< 1nm RMS
Material:
Schott D 263 ®M Cover Glass
Dimension Tolerance:
± 0.20mm
Thickness Range:
No00 (0.06mm to 0.08mm) 0.07mm
No0 (0.085mm to 0.115mm) 0.10mm
No1 (0.13mm to 0.16mm) 0.15mm
No1.5 (0.16mm to 0.19mm) 0.17mm
No1.5H (0.17mm ± 0.005mm) 0.17mm (High Precision)
No2 (0.19mm to 0.23mm) 0.20mm
Edge Finish:
As cut
Surface Quality:
60/40 Scratch/Dig
Surface Roughness:
< 1nm RMS
*Please note part no GPD-1577 plates are pre-cleaned & paper interleaved

Please contact us for discount pricing for stock parts over 10+ and volume/OEM quantities

Currency select:

Part No Data
sheet
Description Dimensions (mm)Thickness (mm) Unit price
(1-10)
Qty
Qty
(10+)Volume pricing available for 10+, please add to quote.
GPD-2501 PDF Cover Glass (10 off per pack) Ø 250.10 £26.00
QTY
Added. View quote
GPD-5510 PDF Glass Slide (5 off per pack) 50 x 500.10 £26.00
QTY
Added. View quote
GPD-5515 PDF Glass Slide (5 off per pack) 50 x 500.15 £26.00
QTY
Added. View quote
GPD-2502 PDF Cover Glass (10 off per pack) Ø 250.20 £26.00
QTY
Added. View quote
GPD-5502 PDF Glass Slide (5 off per pack) 50 x 500.20 £26.00
QTY
Added. View quote
GPD-2503 PDF Cover Glass (10 off per Pack) Ø 250.30 £26.00
QTY
Added. View quote
GPD-5503 PDF Glass Slide (5 off per Pack) 50 x 500.30 £26.00
QTY
Added. View quote
GPD-2504 PDF Cover Glass (10 off per Pack) Ø 250.40 £25.00
QTY
Added. View quote
GPD-5504 PDF Glass Slide (5 off per Pack) 50 x 500.40 £25.00
QTY
Added. View quote
GPD-2505 PDF Cover Glass (10 off per Pack) Ø 250.55 £27.00
QTY
Added. View quote
GPD-5507 PDF Glass Slide (5 off per Pack) 50 x 500.70 £27.00
QTY
Added. View quote
GPD-2507 PDF Cover Glass (10 off per Pack) Ø 250.70 £27.00
QTY
Added. View quote
GPD-5505 PDF Glass Slide (5 off per Pack) 50 x 500.55 £27.00
QTY
Added. View quote
GPD-1577 PDF Glass Slide (50 off per pack) 110 x 740.17 £85.00
QTY
Added. View quote
GPD-4555 PDF Glass Slide (100 off per pack) 45 x 450.55 £70.00
QTY
Added. View quote

Part Number

GPD-2501

Cover Glass (10 off per pack)

PDF Data sheet

Thickness (mm) 0.10

Dimensions (mm) Ø 25

UNIT PRICE (1-50)

£26.00 Inc. VAT

QTY

Part Number

GPD-5510

Glass Slide (5 off per pack)

PDF Data sheet

Thickness (mm) 0.10

Dimensions (mm) 50 x 50

UNIT PRICE (1-50)

£26.00 Inc. VAT

QTY

Part Number

GPD-5515

Glass Slide (5 off per pack)

PDF Data sheet

Thickness (mm) 0.15

Dimensions (mm) 50 x 50

UNIT PRICE (1-50)

£26.00 Inc. VAT

QTY

Part Number

GPD-2502

Cover Glass (10 off per pack)

PDF Data sheet

Thickness (mm) 0.20

Dimensions (mm) Ø 25

UNIT PRICE (1-50)

£26.00 Inc. VAT

QTY

Part Number

GPD-5502

Glass Slide (5 off per pack)

PDF Data sheet

Thickness (mm) 0.20

Dimensions (mm) 50 x 50

UNIT PRICE (1-50)

£26.00 Inc. VAT

QTY

Part Number

GPD-2503

Cover Glass (10 off per Pack)

PDF Data sheet

Thickness (mm) 0.30

Dimensions (mm) Ø 25

UNIT PRICE (1-50)

£26.00 Inc. VAT

QTY

Part Number

GPD-5503

Glass Slide (5 off per Pack)

PDF Data sheet

Dimensions (mm) 50 x 50

Thickness (mm) 0.30

Focal Length (mm) 0

UNIT PRICE (1-50)

£26.00 Inc. VAT

QTY

Part Number

GPD-2504

Cover Glass (10 off per Pack)

PDF Data sheet

Thickness (mm) 0.40

Dimensions (mm) Ø 25

UNIT PRICE (1-50)

£25.00 Inc. VAT

QTY

Part Number

GPD-5504

Glass Slide (5 off per Pack)

PDF Data sheet

Dimensions (mm) 50 x 50

Thickness (mm) 0.40

Focal Length (mm) 0

UNIT PRICE (1-50)

£25.00 Inc. VAT

QTY

Part Number

GPD-2505

Cover Glass (10 off per Pack)

PDF Data sheet

Thickness (mm) 0.55

Dimensions (mm) Ø 25

UNIT PRICE (1-50)

£27.00 Inc. VAT

QTY

Part Number

GPD-5507

Glass Slide (5 off per Pack)

PDF Data sheet

Dimensions (mm) 50 x 50

Thickness (mm) 0.70

Focal Length (mm) 0

UNIT PRICE (1-50)

£27.00 Inc. VAT

QTY

Part Number

GPD-2507

Cover Glass (10 off per Pack)

PDF Data sheet

Thickness (mm) 0.70

Dimensions (mm) Ø 25

Focal Length (mm) 0

UNIT PRICE (1-50)

£27.00 Inc. VAT

QTY

Part Number

GPD-5505

Glass Slide (5 off per Pack)

PDF Data sheet

Dimensions (mm) 50 x 50

Thickness (mm) 0.55

Focal Length (mm) 0

UNIT PRICE (1-50)

£27.00 Inc. VAT

QTY

Part Number

GPD-1577

Glass Slide (50 off per pack)

PDF Data sheet

Thickness (mm) 0.17

Dimensions (mm) 110 x 74

UNIT PRICE (1-50)

£85.00 Inc. VAT

QTY

Part Number

GPD-4555

Glass Slide (100 off per pack)

PDF Data sheet

Thickness (mm) 0.55

Dimensions (mm) 45 x 45

UNIT PRICE (1-50)

£70.00 Inc. VAT
